Agilex™ 3 FPGA and SoC FPGA

Bringing high performance and power to cost-optimized and compact form factor FPGAs, which enables innovators to reach the next level of performance for their optimized designs.​

Agilex 3 FPGAs and SoC FPGAs Product Table

DAM image

Optimized for Cost-Effective and Space-Efficient Designs

Up to

1.9X

Higher fabric performance

Up to

38%

Lower total power

Up to

12.5Gbps

Transcievers

Benefits

Upgraded Performance

Agilex 3 brings the high-performance Hyperflex™ FPGA architecture to power and cost-optimized applications. With 12.5 Gbps transceivers, 1.25 Gbps low-voltage differential signaling (LVDS), and 2.5G MIPI D-PHY, which improves system bandwidth, your data can get into and out of the FPGA, reducing data bottlenecks.

Higher Integration

AI-optimized DSPs with tensor blocks and hardened IP blocks deliver robust capabilities in a single chip while supporting dual ARM* Cortex*-A55 cores. Utilizing innovative variable pitch BGA packaging technology enables these capabilities while maintaining low-cost manufacturing PCB design rules.

Security and Reliability

With Security Device Manger (SDM), this product family offers advanced security features such as post quantum cryptography (PQC) native boot, bitstream encryption and authentication, physically unclonable function (PUF) key storage, and physical anti-tamper to secure your designs.

Key Features

Enhanced DSP with AI Tensor Block

Offers up to 2.8 peak INT8 TOPS with FPGA AI Suite support to enable push-button flow from industry standard frameworks to FPGA bitstream.

Transceivers​

The GTS transceiver supports data rates up to 12.5 Gbps. It integrates hard IP support for PCIe 3.0 x4 and 10GbE, reducing design time and on-chip resources required.

SDM (Secure Device Manager)

Offering key security features such as secure boot, AES encryption, and FPGA configuration management, which runtime sensors and tamper detection, providing ensure authenticated FPGA configuration, support bitstream encryption, and manage enhanced protection against unauthorized access and data integrity threats.

Applications

DAM image

Industrial

View Detail Right arrow Right arrow
DAM image

Medical

View Detail Right arrow Right arrow
DAM image

Consumer Electronics

View Detail Right arrow Right arrow
DAM image

Security

View Detail Right arrow Right arrow
DAM image

Broadcast and Pro AV

View Detail Right arrow Right arrow

Products & Ordering

file Icon Active file Icon Product Table
file Icon Active file Icon Ordering Part Number Guide
file Icon Active file Icon Contact Distributor
Agilex 3 Product Badge

Start Developing with Agilex 3

Build compact, power-efficient embedded systems for edge AI, control, and vision applications.
